Arduino Uno R3 DIP
Official Arduino Uno R3 – Made in Italy | ATmega328P, 16MHz, 32KB Flash, 14 Digital I/O, USB Type-B | Original Arduino Board The Official Arduino Uno R3 is the genuine,...
Read MoreSKU:ARD-014
- Regular price
- Rs. 701.50
- Sale price
- Rs. 701.50
- Regular price
-
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Official Arduino Uno R3 – Made in Italy | ATmega328P, 16MHz, 32KB Flash, 14 Digital I/O, USB Type-B | Original Arduino Board
The Official Arduino Uno R3 is the genuine, Italy-manufactured edition of the world's most widely used microcontroller board — the first in Arduino's USB board series and the definitive starting point for electronics learning and embedded development. Built around the ATmega328P running at 16MHz with 32KB flash (31.5KB usable), 2KB SRAM, and 1KB EEPROM, it provides 14 digital I/O pins (6 PWM) and 6 analog inputs alongside USB Type-B, a DC barrel jack, ICSP header, and reset button. Compatible with every Arduino shield, library, and sketch — connect via USB and start building immediately.
- Official Arduino, Made in Italy – genuine board manufactured by Arduino, certified quality
- ATmega328P microcontroller – proven, well-documented AVR MCU with massive community support
- 14 digital I/O pins, 6 PWM – drive LEDs, motors, servos, relays, and displays
- 6 analog inputs (10-bit ADC) – read sensors, potentiometers, and analog signals
- USB Type-B programming – standard cable, plug into any computer and program instantly
- Dual power input – USB (5V) or DC barrel jack (7–12V, max 20V) with onboard regulation
- Full shield & library compatibility – works with every Arduino Uno shield and sketch ever written
- 16MHz ceramic resonator – stable, consistent timing for all timing-critical applications
Ideal Applications
- Learning electronics, embedded programming, and Arduino for beginners
- Robotics, servo control, and autonomous vehicle projects
- IoT sensors, home automation, and environmental monitoring
- Sensor interfacing: temperature, humidity, ultrasonic, IR, and more
- Motor driver shields, relay control, and power switching projects
- STEM education, maker labs, and classroom electronics kits
Technical Specifications
| Feature | Specification |
| Microcontroller | ATmega328P |
| Clock Speed | 16 MHz (ceramic resonator) |
| Flash Memory | 32KB (0.5KB used by bootloader) |
| SRAM | 2KB |
| EEPROM | 1KB |
| Operating Voltage | 5V DC |
| Input Voltage | 7–12V (recommended), max 20V |
| Digital I/O Pins | 14 (6 with PWM output) |
| Analog Input Pins | 6 |
| DC Current per I/O Pin | 40mA |
| DC Current (3.3V Pin) | 50mA |
| USB Interface | Standard USB Type-B |
| Other Interfaces | DC barrel jack, ICSP header, reset button |
Pin Diagram
What's in the Box
- Official Arduino Uno R3 Development Board × 1
Note: USB cable and power supply are not included. This is an official Arduino board manufactured in Italy — not a clone or third-party replica.
